| Normal environmental conditions | ||
| Operating temperature | ||
| Storage temperature | -25～50℃ | |
| Humidity | -30～70℃ | |
| Atmospheric | 95％RH ,non-condensing | |
| Altitude | 70～106kPa | |
| Vertical inclination angle | ≤2000m | |
| Mounting method | Max 5% | |
| Mounted free from | Floor/ground mounted | |
| Fire damp,heavy dampness, explosive gas | ||
| Characteristics of power input | ||
| Input AC power type | 3 phase+Neutral+PE | |
| Input AC voltage | 400V±15% | |
| Input AC frequency | 45～65Hz | |
| Power factor | ≥0.99 20~100%@20~100% load | |
| Efficiency | ≥95% @nominal output power | |
| Turn on inrush current | ≤110% peak value of rated input current | |
| Input undervoltage protection | 255±5V (adjustable,de-rating output below 300V) | |
| Input overvoltage protection | 535±5V (adjustable,de-rating output above 500V) | |
| Standby power consumption | ＜100W | |
| THDi | ＜5% | |
| Characteristics of power output | ||
| Charging standard | CCS2 DC | |
| Output voltage range | 150～1000V | |
| Output current range | 0～250A | |
| Output power | 90kW | |
| 180kW | ||
| Output voltage tolerance | ±0.5% | |
| Output voltage ripple | ≤±5V | |
| Output voltage stability | ±0.5% | |
| Output current tolerance | ≤5A: ≤±150mA | |
| 5~50A:≤±1.5A | ||
| 50~200A:≤±1% | ||
| Output current ripple | f≤10Hz:≤1.5A | |
| f≤5000Hz:≤6A | ||
| f≤150kHz:≤9A | ||
| Output current stability | ±1% | |
| Voltage measurement accuracy | ±5V | |
| Current measurement accuracy | ±（1.5%×Im+1) | |
| Energy measurement accuracy | 1.00% | |
| Auxiliary power | —— | |
| Protection | Over current | ＞300A |
| Short current | 50kA | |
|
Insulation resistance |
≥100ΩV x U | |
